Complete underlayable terrace support system
Terrace support system with optional pressure disc for quick and precise terrace construction on sealed surfaces.
Function
Terrace support for the installation of all surface types, particularly stone slabs and boardwalk finishes. The height adjustment and equalizing elements permit easy levelling of surfaces and slopes. In combination with the pressure disc, which is available as an accessory, the KALA support forms a sliding support system for direct installation on seals. Additional protective mats must be fitted in areas frequented by the public, such as entrances to public buildings, cafeterias, etc.
Material
KALA terrace support systems are constructed from black FPO/PP: A weatherproof, UV-stabilized and highly low-temperature impact resistant plastic.
Versions
| Height mm | Diameter mm |
|---|---|
| 21 | joint divider 3 mm, D 120 |
Examples
Technical drawings
| Technical data | ||
|---|---|---|
| Underlayable terrace support system | ||
| D1 | 250 | mm |
| D2 | 120 | |
| Ft | 3, alternatively 4 | |
| H | 21 | |
| HG | 18 | |
| HF | 3 | |
| HD | 7 | |
| h | 16 | |
| b | 14 | |
| Optional equalising elements: Equaliser disc, splits into quarters H=3 mm, Equaliser ring for underlayable terrace support systems H=6 mm | ||
Package units
- Supplied in cartons, each containing 100 units
- Support (joint divider and basic element) or joint divider solo, basic element solo
Tailored to meet your requirements
Do you have any questions or require a customised version of this product? Talk to our team of experts! We’ll discuss the available options with you to see how we can help!
